Assembly/Setup
a. Remove existing drill guide from the Kreg Jig 720 by squeezing the tabs
(1) on both sides and lifting forward and up to remove the drill guide from
the carriage of the Kreg Jig.
b. Insert the Plug Cutter Drill Guide (A) into the carriage by squeezing the
tabs (1) on both sides of the drill guide carriage, inserting the bottom tab
of the Plug Cutter Drill Guide (A) into the slot on the Kreg Jig carriage and
pressing the top of the Plug Cutter Drill Guide (A) into place.
1
A
