Kreg KPHJ230 - Using the Jig for Repair Applications

11
Using the Jig for Repair Applications
a. Remove the material thickness stop (B).
b. Position the jig on the workpiece.
c. Clamp and drill the pocket-holes.
Note The position of the stop collar on the drill bit does not change.
B
1/2"
(12.7 mm)
