Kreg KPHJ230 - Position the Material Thickness Stop; Configure the Jig

5
3
Position the Material Thickness Stop
a. Push and slide the material thickness stop (B) to the desired setting.
B
4
Configure the Jig
a. Insert and rotate the drill guide (A) into the other drill guide.
b. Slide the drill guide forward to join.
Note To remove, pull back and rotate the drill guide to separate.
A
