Kreg KPHJ230 - Recommended Hole Spacing Configurations

7
Tip If you cannot use a clamp, secure the jig with screws in the screw recesses.
Recommended Hole Spacing Configurations
Narrow Pieces
1-1/2" – 2"
(38 mm – 51 mm)
3-1/2"
(89 mm)
6" – 8"
(15 cm – 20 cm)
6" – 8"
(15 cm – 20 cm)
5/8" – 1-1/2"
(15 mm – 38 cm)
Wide Pieces
Place pocket holes 5/8" to 1-1/2 in. from edge, then every 6-8 in.
1-1/2" – 2"
(38 mm – 51 mm)
3-1/2"
(89 mm)
6" – 8"
(15 cm – 20 cm)
6" – 8"
(15 cm – 20 cm)
5/8" – 1-1/2"
(15 mm – 38 cm)
