Kreg KPHJ920 - Recommended Hole Spacing; Clamp the Joint in Place

6
Recommended Hole Spacing
1" 1"
2x6 2x82x4 or 4x4
3½"
(89 mm)
5½"
(140 mm)
7¼"
(184 mm)
1¾"81½"1½"1¼" 1¼" 1¾"8
1½"1½" 1½"
2
Clamp the Joint in Place
Note Clamping secures the workpieces and gives you a better nished joint.
a. Clamp here for the face joint. b. Clamp here for the edge joint.
