Kreg KPHJ920 - Helpful Tips; Using the Clamp Pad Adapter

8
Tips
Using the Clamp Pad Adapter
The clamp pad adapter connects the jig to the clamp.
a. Position the clamp in the adapter (G) and slide closed.
b. Seat the rubber anchor of the adapter (G) in the drill guide (A) as indicated in section view
below.
Note Do not block the chip ejection hole (1).
1
G
G
A
