13
4 Cut Your Material
a. Once the guide is set into place, slide the cutline indicator arms (F) away from
the cut line.
b. Double-check the blade depth on your tool is correct, allowing 1/8" more than
your material thickness (refer to the tool’s owners manual for setting depth).
Position the tool against the guide rail making sure the blade is not in contact
with the material.
c. Start the tool and allow the blade to get up to full speed. Then begin the cut.
Follow the guide rail, ensuring your tool hugs against the guide until the cut is
complete.
5 Remove the Straight Edge Guide from the Material
Remove the straight edge guide from the material by placing one hand on the
material and pulling back and up on the handle (H) to release.
H
To Next Page
