9
EN
1.
Ultrasonic sensor (Only for KR172E.A, KR173E,
KR174E)
14. Cutting Blade
2. Charging Strips 15. Charging Pile
3. Rear Driving Wheel 16. Contact Pins
4. Rain Sensor 17. Charging Base
5. STOP Button 18. Power Adapter
6. Display 19. Charging Base Fixing Nails
7. Keypad 20. RTK Antenna
8. ON/OFF Key 21. Hex Key
9. START Key 22. Wrench for RTK antenna
10. Front Wheel 23. Magnetic Strip
11. Blade Turning Disc 24. Staples
12. Battery Pack * 25. Hexagon Screwdriver * (Only for KR174E)
13. Handle 26. Buckle
*Not all the accessories illustrated or described are included in standard delivery.
Technical data
Type KR172E KR172E.A KR173E KR174E (100-199 - designation of machinery, representative of
Robotic Lawnmower)
KR172E KR172E.A KR173E KR174E
Rated voltage
20V Max.*
No load speed 2700/min 2600/min
Cutting area 2000m
2
3000m
2
5000m
2
Cutting diameter 20cm 22cm
Cutting height 30-60mm
Cutting height
positions
7
Battery type Lithium-ion
Battery model KA3024 KA3006
Charging time approx. 180 min 90 min 72 min
Charger model KA0200 / KA0201 KA3710/KA3711 KA3719/KA3819
Charger rating
Input: 100-240V~50/60Hz,
38W,
Output: 20V, 1.5A
Input: 100-240V~50/60Hz,
90W,
Output: 20V, 3.0A
Input: 100-240V~50/60Hz,
190W,
Output: 28V, 5.0A
Machinery weight 12kg 12.2kg 12.6kg
Protection degree III
App Y
Maximum slope within
the work surface
40%
* Voltage measured at no load. Initial battery voltage reaches maximum of 20 volts. Nominal voltage is 18 volts.
