KROHNE DK32 - Page 19

INSTALLATION 3
19
VA FLOWMETERS
www.krohne.com09/2022 - 4000419908 - AD VA Mech Ex Gb-Db R08 en
Figure 3-3: Ground terminal for DK37/M8M
Figure 3-4: Ground terminal for H250/M8MG
INFORMATION!
The indicator housing of M8M is made of conductive plastic. Friction cannot cause electrostatic
charge.
Figure 3-5: Ground terminal for DK46 / DK47 / DK 48 / DK800
