6
For Ex i outputs
Ex d connection compartment Ex e connection compartment
II 2(1) G Ex d [ia/ib] IIC T6 Gb II 2(1) G Ex de [ia/ib] IIC T6 Gb
II 2(1) D Ex ib t [ia Da] IIIC T80°C Db II 2(1) D Ex ib t [ia Da] IIIC T80°C Db
F
or non-Ex i outputs
II 2 G Ex d [ib] IIC T6 Gb II 2 G Ex de [ib] IIC T6 Gb
II 2 D Ex ib t IIIC T80°C Db II 2 D Ex ib t IIIC T80°C Db
Power Supply Circuit Data Circuit
MFC 300F MFC 300F T6 MFC 300F / MFC 300F T6
Uo = 16.5 V Uo = 16.5 V Uo = 6 V
Io = 305 mA Io = 262 mA Io = 33 mA
Po = 1.25 W Po = 1.07 W Po = 120 mW
Characteristic curve: linear
Co = 230 nF Co = 240 nF Co = 1.9 μF
Lo = 320 μH Lo = 450 μH Lo = 2 mH
For details of the signal output values, compare the table in section 4 with the CG32…….XYZ
number listed on the data label.
The output connections to the mass flow sensor have the following values:
1.2 MFC 300F & MFC 300F T6
The MFC 300F & MFC 300F T6 have intrinsically safe connections to the mass flow sensor with either
increased safety or intrinsically safe signal outputs. The signal output connection compartment can be
configured with protection type Ex d or Ex e. The marking is as follows:
MA_Haz_Areas_Rev_08_en.qxp 26/07/2012 16:20 Page 6
