33
• The options separated with “/” are software selectable (can be changed by user)
• The options separated by “or” are hardware versions (must be ordered as such)
• All outputs are passive unless otherwise indicated
• HighC means High Current input/output, Namur means input/output to Namur recommen-
dations
OOvveerrvviieeww ooff ppoossssiibbllee ccoommbbiinnaattiioonnss,, ddeeffiinneedd bbyy tthhee CCGG3322 nnuummbbeerr
CChhaarraacctteerrss
XXYYZZ
NNaammee II//OO
cciirrccuuiittss
TTeerrmmiinnaallss AA,, AA-- TTeerrmmiinnaallss BB,, BB-- TTeerrmmiinnaallss CC,, CC-- TTeerrmmiinnaallss DD,, DD--
100
Basic I/O CO CO (a) over A+ SO/CI SO PO/SO
488 to 4RR
588 to 5RR
688 to 6RR
788 to 6RR
888 to 8RR
A88 to ARR
B88 to BRR
C88 to CRR
Modular I/O or
Modular Carrier
with 1 or 2 I/O
Modules
Many combinations possible
D88
Fieldbus I/O
Profibus PA
n.c. n.c. PA PA
D8A to DRR
Fieldbus I/O
Profibus PA with
Module Carrier
with 1 or 2 I/O
Modules
many combinations possible PA PA
E88
Fieldbus I/O
Foundation
Fieldbus
n.c n.c FF FF
E8A to ERR
Fieldbus I/O
Foundation
Fieldbus with
Module Carrier
with 1 or 2 I/O
Modules
many combina-
tions possible
FF FF
F00 Profibus DP I/O n.c DP(a) DP(a) DP(a)
F80 to FRO
Profibus DP I/O
with 0 or 1 I/O
many combina-
tions
DP(a) DP(a) DP(a)
G00 to GRR RS485 Modbus
Many combinations possible RS485 RS485
H00 to HRR
Modbus with 1 or 2
I/O modules
• shorts for in/output functions: CO= current output, PO=Pulse Output, SO= Status Output, CI= Control
Input, PA=Profibus PA, FF=Foundation Fieldbus, DP=Profibus DP; RS458= RS485 Modbus.
• all in/outputs are passive unless otherwise noted as active (a)
• n.c. = not connected.
