Krone EasyCut F 320 M - Filling Quantities and Lubrication Designations for Gearboxes; Oil Level Check and Oil Change Intervals (Gearboxes); Angular Gearbox

Maintenance
47
Pos: 24.19 /Übersc hriften/Überschrif ten 2/F-J/Füll mengen und Sc hmiermittelbe zeichnungen der Getriebe @ 0\m od_11969510 94046_78.doc x@ 15335 @ 2 @ 1
10.5 Filling Quantities and Lubrication Designations for Gearboxes
Pos: 24.20 /Ab kürzungen /Abkürz ungen sprac hneutral/EasyC ut/EasyCut F 280 / EasyCut F 320 @ 89\mod_132 2659005577_ 0.docx @ 765650 @ @ 1
(EasyCut F 280 / EasyCut F 320 )
Pos: 24.21 /BA/ Wartung/Tabelle n_Füllmengen/M ähwerke/Technisc he Daten B etriebsstoffe Füll mengen Eas yCutF 280 / F 320 @ 103\mod_133 2229525090_ 78.docx @ 94065 7 @ @ 1
Filling
quantity
Filtered oils
Bio-degradable
lubricants
[Litres] Brand name Brand name
Angular gearbox 1.0 l
SAE90
On request
Cutter bar EasyCut F 280 6.0 l
Cutter bar EasyCut F 320 7.0 l
Pos: 24.22 /Ab kürzungen /Abkürz ungen sprac hneutral/EasyC ut/EasyCut F 360 @ 103\mod_1332 231685654_0. docx @ 940 891 @ @ 1
(EasyCut F 360)
Pos: 24.23 /BA/ Wartung/Tabelle n_Füllmengen/M ähwerke/Technisc he Daten B etriebsstoffe Füll mengen Eas yCutF 360 @ 10 3\mod_13322298 80618_78.doc x @ 940775 @ @ 1
Filling
quantity
Filtered oils
Bio-degradable
lubricants
[Litres] Brand name Brand name
Angular gearbox 1.0 l
SAE90
On request
Cutter bar EasyCut F 360 8.0 l
Pos: 24.24 /Ab kürzungen /Abkürz ungen sprac hneutral/EasyC ut/EasyCut F 280 M / EasyCut F 32 0M @ 89\mod _132265891758 6_0.docx @ 765 622 @ @ 1
(EasyCut F 280 M / EasyCut F 320 M)
Pos: 24.25 /BA/ Wartung/Tabelle n_Füllmengen/M ähwerke/Technisc he Daten B etriebsstoffe Füll mengen Eas yCutF 280 M / F 3 20 M @ 103\ mod_1332229948 592_78.doc x@ 9 40804 @ 3 @ 1
Filling
quantity
Filtered oils
Bio-degradable
lubricants
[Litres] Brand name Brand name
Angular gearbox 0.5 l
SAE90
On request
Mower drive gearbox 0.4 l
Cutter bar EasyCut F 280 M 6.0 l
Cutter bar EasyCut F 320 M 7.0 l
Pos: 24.26 /Ab kürzungen /Abkürz ungen sprac hneutral/EasyC ut/EasyCut F 360 M @ 103\mod_13 32231660639 _0.docx @ 9 40862 @ @ 1
(EasyCut F 360 M)
Pos: 24.27 /BA/ Wartung/Tabelle n_Füllmengen/M ähwerke/Technisc he Daten B etriebsstoffe Füll mengen Eas yCutF 360 M @ 103\mod_133222 9689401_78.doc x @ 940746 @ @ 1
Filling
quantity
Filtered oils
Bio-degradable
lubricants
[Litres] Brand name Brand name
Angular gearbox 0.5 l
SAE90
On request
Mower drive gearbox 0.9 l
Cutter bar EasyCut F 360 M 8.0 l
Pos: 24.28 /BA/ Wartung/Zeitinter valle an den Ge trieben 200 h @ 0\mod_11969 51919921_78.doc x @ 15373 @ 23@ 1
10.5.1 Oil Level Check and Oil Change Intervals (Gearboxes)
Note - Oil level check and oil change (gearboxes) and lubricating the machine
Effect: Long expected service life of machine
• First oil change on all gearboxes after 50 operating hours, then every 200 operating
hours (but at least once a year).
• Before using the machine always check the oil level.
• With bio-degradable oils the changing intervals must be complied with absolutely
because of ageing of the oils.
Pos: 24.30.1 /Üb erschriften/Üb erschriften 2/U-Z/ Winkelgetriebe @ 0\mod_1197 005918299_7 8.docx @ 15435 @ 2 @ 1
10.6 Angular gearbox
