R E P A I R

Generaldisassembly

Thegeneraldisa ssembly

 makesimportantcomponentsaccessibleforrepairorreplacement,

 isrequiredfortheleakagecheck .

Safetyinformation

• Emptythefluidsystem beforerepair(ifpossible)an dshipment(seeseepage18).

• Thehousingbackisassembledwithspecialsafetyscrews.Pleaseinsertthesame

screwswhenreassemblingthemachineforsafetyreasonsfortheuser.

• Witheachrepair

 alwaysaccomplishinternalcleaning

 renewallpressurehosesandcl ipswhendisassembled.

• Handlesnapconnection sandlatcheswithcaretoavoidanydamage.

• Ifitisnecessarytocutorpulloffhoses,holdatowelreadytowipe awayleakingwater.

Preparationfordisassembly

1. Removewatertank( A),capsuleholder(B)anddriptray(C)togetherwithdripgrid.

General disassem-

bly is presented as

step by step instruction.

Pay attention to the

sequence of disassembly

steps, e.g. housing front

cannot be removed

before housing back is

unscrewed.

WA R NI NG

Dangerofelectricshocklivepartsinside coffeemachine.

Unplugfromthemainsbeforedisassemblingthemachine

appliancemustbeisolated!

Everytimeapressurehoseoraclipisdisconnected,itmustbereplaced

byanewone.

Unplug machine

from the mains

before disassembling -

appliance must be

isolated!
