Krups KP 5002 - Securing Extraction Head

R E P A I R
Fasteningashakyextractionhead
Afterimpactstress,fallingdown,holdingthelockinghandleandliftingthemachineetc.
thelatch andscrewconnectionsbet weenextractionheadandc enterpartcanbecome
loose.
1.Removehousingrightandleft.
2. Checkift he2screws(n)arepresent.
3. Replaceorfastenscrews.
4. Checkifextractionheadissteady now.
The extraction head
is mounted on the
centerpart with 2 addi-
tional screws.
Use only torx
screws 3 x 15 mm
for thermoplastics.
