Krups KP 5002 - Replacing Power Cord and Fuses

R E P A I R
Replacingpowercordwiththermofuses
1.Removehousingrightandleftwithspacers.
2. Unplug2flatreceptaclesfrommainPCB(O).
3. Unplugflatrec eptaclefrompump(T).
4. Removelineandneutralwiresfromcableguidesincenterpart.
5. Unplugflatrec eptaclefromthermoblock(Z).
6. Loosen screw andremovefuseholder(e).
Defective thermo
fuses can only be
replaced together with
the power cord.
Power cord wires
have country-spe-
cific color code.
Theflatreceptacleshaveaspecialconnectorlatching.
Pressdownleveratfirst,thenpullreceptacle.
