2.2 Measurement scales
 The device contains two
measurement scales: refractive index
(nD) and concentration of sucrose
[%Brix].
 The designation BRIX (1) indicate
the measurement scale of the
concentration of sucrose and RI (2)
indicate the refractive index.
▪ By pressing the SCALE button (3) you can switch between both measurement
scales. The arrow in the display indicates which measurement scale is activated.
 Various conversion tables are included for information, see chapter 4.4 Tables.
2.3 Type plate
POS
Designation
1
Manufacturer’s address
2
WEEE-registration number (according to directive 2012/19/EU)
3
Device type
4
Serial number
5
Electrical data
6
CE-mark
 The type plate is located on the bottom of the device.
Figure 2 – Measurement scales
1
2
3
Figure 3 – Type plate
1
2
3
4
5
6
