9 Related Documents
107 of 128
Amarex KRT
9.2.7 Special feature of hydraulic system - pump set with cooling system
412.15
920.27
902.27
412.04
163
Fig.75: Special feature of hydraulic system - pump set with cooling system
Table56: List of components
Part No. Description Part No. Description
163 Discharge cover 902.27 Stud
412.04/.15 O-ring 920.27 Nut
9.2.8 Special feature of hydraulic system - pump set without cooling system
412.15
163
902.27
920.27
412.04
412.24
471
412.40
Fig.76: Special feature of hydraulic system - pump set without cooling system
Table57: List of components
Part No. Description Part No. Description
163 Discharge cover 902.27 Stud
412.04/.15/.24/.40 O-ring 920.27 Nut
471 Seal cover
