KSB Controlmatic E.2 User Manual

5 Installation at Site
12 of 24
Controlmatic E.2
5 Installation at Site
5.1 Safety regulations
DANGER
Incorrect installation
Danger to life!
▷ Install the automatic control unit in a flood-proof location.
▷ Never install the automatic control unit in potentially explosive atmospheres.
▷ The automatic control unit is not suitable for controlling pumps in potentially
explosive atmospheres.
5.2 Checks to be carried out prior to installation
The place of installation must meet the following requirements:
▪ Dry
▪ Frost-proof
▪ Well ventilated
▪ Lockable; unauthorised access must be prevented.
▪ Flood-proof
▪ Installation in potentially explosive atmospheres is not permitted.
Ambient conditions
The ambient conditions specified in the following table must be observed:
Table8: Ambient conditions
Characteristic Value
Temperature during operation 0 °C to +50 °C
Relative humidity Non-condensing
Installation altitude Max. 1,000m above MSL
5.3 Connecting the automatic control unit
CAUTION
Automatic control unit lifted by the cable
Damage to the automatic control unit!
▷ Do not lift the automatic control unit by the cable.
▪ Remove the automatic control unit from the original packaging.
▪ Mount the automatic control unit in the vertical position directly on the pump.
▪ For wet-installed pumps, mount the automatic control unit to the rigid discharge
pipe in a flood-proof location. (ðSection5.4.2,Page13)
▪ The automatic control unit comes with a screwed-on pressure gauge.
5.4 Connecting the piping
Connect all piping without transmitting any stresses or strains.
5.4.1 Connecting the piping (dry installation)
▪ The automatic control unit can be connected directly to the pump discharge
nozzle.
▪ Always mount the automatic control unit in the vertical position.
