KTM 1290 SUPER ADVENTURE R 2017 User Manual

15 WHEELS, TIRES 182
15.1 Removing the front wheel
Preparatory work
– Raise the vehicle with the center stand. ( p. 138)
V00006-10
Main work
– Place a load on the rear of the vehicle.
The front wheel is not in contact with the ground.
–
Remove screw
1
and pull wheel speed sensor
2
out of the hole.
S00959-10
–
Remove screws
3
from both brake calipers.
– Press back the brake linings with a slight lateral tilting of the brake calipers on the
brake disc.
– Pull the brake calipers carefully back from the brake discs and hang them to one side
loosely.
Info
Do not pull the hand brake lever when the brake caliper has been removed.

KTM 1290 SUPER ADVENTURE R 2017 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.1:1
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Front Suspension	WP USD Ø 48 mm
Front Wheel	2.50 x 21"
Rear Wheel	4.50 x 18"
Front Tire	90/90-21
Rear Tire	150/70-18
Seat Height	890 mm
Ground Clearance	250 mm
Fuel Capacity	23 liters
Dry Weight	217 kg
Power	118 kW (160 hp) @ 8, 750 rpm
Torque	140 Nm @ 6750 rpm
Fuel System	Keihin EFI
Frame	Chromoly steel trellis frame, powder coated
Rear Suspension	WP monoshock
Front Brake	2 x 320 mm discs, 4-piston radial fixed caliper
Rear Brake	Brembo two-piston caliper, 267 mm disc
ABS	Bosch 9ME Combined-ABS
Wheelbase	1580 mm
