KTM 1290 Super Duke GT Series User Manual

3 WORK 7
3.1 Removing the passenger seat
S01106-10
–
Insert the ignition key in seat lock

and turn it clockwise.
– Raise front of the passenger seat, pull toward the tank, and remove upward.
– Remove the ignition key.
3.2 Mounting the passenger seat
402652-10
–
Attach the hooks on the passenger seat to seat mounts

.
– Lower the passenger seat and push back.
–
Position locking pin

in the lock housing and push down the passenger seat at
the front.
The locking pin engages with an audible click.
– Check that the passenger seat is correctly mounted.
3.3 Removing the front rider's seat
Preparatory work
– Remove the passenger seat. ( p. 7)
S01104-10
Main work
–
Press seat release

in the direction of the arrow and lift the front rider's seat at
the rear at the same time.
– Detach the front of the front rider's seat and remove it.
3.4 Mounting the front rider's seat
401921-10
Main work
–
Attach recesses

on the front rider's seat to the fuel tank, push the front rider's
seat forward.
–
Position locking pin

in the lock housing and push down the front rider's seat at
the rear.
The locking pin engages with an audible click.
– Check that the front rider's seat is correctly mounted.
Finishing work
– Mount the passenger seat. ( p. 7)

KTM 1290 Super Duke GT Series Specifications

General

Displacement	1301 cc
Transmission	6-speed
Bore x Stroke	108 mm x 71 mm
Front Tire	120/70 ZR17
Rear Tire	190/55 ZR17
Torque	140 Nm @ 8000 rpm
Fuel Capacity	23 liters
Seat Height	835 mm
Cooling System	Liquid Cooled
Front Suspension	WP USD Ø 48 mm
Rear Suspension	WP monoshock
Front Brake	Dual 320 mm discs, 4-piston calipers
Rear Brake	Single 240 mm disc, 2-piston caliper
Traction Control	MTC (Motorcycle Traction Control)
Frame	Chromoly steel trellis frame, powder coated
Dry Weight	205 kg
Wheelbase	1482 mm
