2 SETUP 5
L01507-01
– Remove the passenger seat. ( p. 6)
– Secure the tool set with the rubber holder.
L01505-01
– Carefully loosen and remove the tensioning belt from the frame.
Info
An assistant prevents the motorcycle from falling over.
– Carefully loosen and remove the tensioning belts around the fork legs.
The vehicle is released at the front.
– Together with an assistant, take the vehicle off the pallet.
– Remove the radiator shield.
L01508-10
– Remove the front rider's seat. ( p. 6)
–
Remove screw
.
–
Lift cover
at the rear and pull toward the rear.
– Fold up the cover.
–
Plug in the connector of starter relay
.
– Recharge the battery. ( p. 7)
– Remove the protective plastic.
– Refuel. ( p. 9)
– Print out the current PDIform found on the KTM Dealer.net and perform the pre-
delivery inspection.
