TROUBLESHOOTING 91
Faults Possible cause Action
The engine cannot be cranked (elec-
tric starter)
(EXC‑F, EXC‑F SIX DAYS, XCF-W)
Operating error – Go through the steps of starting the engine.
( p. 31)
Battery discharged –
Recharge the battery. x ( p. 74)
–
Check the charging voltage. x
–
Check the stall current. x
–
Check the generator. x
Fuse blown – Remove the fuse. ( p. 75)
– Replace the fuse. ( p. 75)
Starter relay defective –
Check the starter relay. x
Starter motor defective –
Check the starter motor. x
Engine turns but does not start Operating error – Go through the steps of starting the engine.
( p. 31)
Motorcycle was out of use for a long
time and there is old fuel in the float
chamber
–
Empty the carburetor float chamber. x
( p. 86)
Fuel feed interrupted – Check the fuel tank breather.
– Clean the fuel tap.
–
Check/adjust the carburetor components. x
Engine flooded – Clean and dry the spark plug or replace if nec-
essary.
Spark plug oily or wet – Clean and dry the spark plug or replace if nec-
essary.
Electrode distance (plug gap) of spark
plug too wide
– Adjust the plug gap.
Guideline
Spark plug electrode gap
0.7 mm (0.028 in)
Defect in ignition system –
Check the ignition system. x
Short-circuit cable in wiring harness
frayed, short-circuit button or emer-
gency OFF switch defective
– Check the wiring harness. (visual check)
– Check the electrical system.
Plug connector of CDI control device,
pulse generator or ignition coil oxi-
dized.
– Clean the plug connector and treat it with con-
tact spray.
Water in carburetor or jets blocked –
Check/adjust the carburetor components. x
Engine has no idle Idling jet blocked –
Check/adjust the carburetor components. x
Adjusting screws on carburetor dis-
torted
–
Carburetor - adjust the idle speed. x
( p. 85)
Spark plug defective – Change spark plug.
Ignition system defective –
Check the ignition coil. x
–
Check the CDI controller. x
–
Check the spark plug connector. x
–
Check the ignition pulse generator. x
–
Check the generator. x
Engine does not speed up Carburetor running over because float
needle dirty or worn.
–
Check/adjust the carburetor components. x
Loose carburetor jets –
Check/adjust the carburetor components. x
Ignition system defective –
Check the ignition coil. x
–
Check the CDI controller. x
–
Check the spark plug connector. x
–
Check the ignition pulse generator. x
–
Check the generator. x
Engine has a lack of power Fuel feed interrupted – Check the fuel tank breather.
– Clean the fuel tap.
–
Check/adjust the carburetor components. x
