11 TUNING THE CHASSIS
60
Info
Adjust the spring preload to the numerical values only
as the preload will not engage between the numerical
values.
Turn clockwise to increase the spring preload; turn
counterclockwise to reduce the spring preload.
Adjusting the spring pretension has no influence on the
absorption setting of the rebound.
Basically, however, you should set the rebound damp-
ing higher with a higher spring pretension.
Finishing work
– Remove the motorcycle from the lift stand. ( p. 63)
11.15 Handlebar position
M00993-10
(All standard EXC/XC-W models)
On the upper triple clamp, there are 2 holes at a distance
of
A
to each other.
Hole distance A 15 mm (0.59 in)
The holes on the handlebar support are placed at a distance
of
B
from the center.
Hole distance B 3.5 mm (0.138 in)
The handlebar can be mounted in four different positions. This
allows the handlebar to be mounted in the most comfortable
position for the rider.

KTM 300 EXC 2018 Specifications

General

Displacement	293.2 cm³
Bore x Stroke	72 mm x 72 mm
Transmission	6-speed
Fuel System	Keihin PWK 36S AG
Rear Suspension	WP Xplor PDS Shock Absorber
Seat Height	960 mm
Ground Clearance	370 mm
Weight (without fuel)	103 kg
Engine Type	2-stroke
Frame	Central-Tube Frame
Front Suspension	WP Xplor 48
Front Brake	260 mm disc
Rear Brake	220 mm Disc Brake
Fuel Capacity	9.5 l
