KTM 890 Adventure 2021 - Left Side Cover and Storage Compartment Operations

3 WORK
14
3.6 Removing the left side cover
Preparatory work
– Remove the passenger seat. ( p. 12)
– Remove the front rider's seat. ( p. 13)
F03348-10
Main work
– Remove left side cover from the rubber bushings in the
areas
A
and
B
.
– Pull off the left side cover sideways and remove it toward the
front.
3.7 Opening the storage compartment on the left
Preparatory work
– Remove the passenger seat. ( p. 12)
– Remove the front rider's seat. ( p. 13)
– Remove the left side cover. ( p. 14)
F01898-10
Main work
–
Lift the elastic fastener
1
and detach in area
A
.
– Open storage compartment.
