3 WORK
16
3.10 Removing the right side cover
Preparatory work
– Remove the passenger seat. ( p. 12)
– Remove the front rider's seat. ( p. 13)
F03350-10
Main work
–
Remove the side cover from the rubber bushings in areas
A
and
B
.
– Pull off the right side cover sideways and remove it toward the
front.
3.11 Opening the storage compartment on the right
Preparatory work
– Remove the passenger seat. ( p. 12)
– Remove the front rider's seat. ( p. 13)
– Remove the right side cover. ( p. 16)
F01900-10
Main work
–
Lift the elastic fastener
1
and detach in area
A
.
– Open storage compartment.
