13 SERVICE WORK ON THE CHASSIS
152
F02736-10
– Position the brake line.
–
Mount and tighten screw
1
.
Guideline
Remaining screws,
chassis
M5 5 Nm (3.7 lbf ft)
13.5 Cleaning the dust boots of the fork legs
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 148)
– Lift the motorcycle with the front lifting gear. ( p. 149)
K01358-10
Main work
–
Push dust boots
1
of both fork legs downward.
Info
The dust boots remove dust and coarse dirt particles
from the inside fork tubes. Over time, dirt can accumu-
late behind the dust boots. If this dirt is not removed,
the oil seals behind can start to leak.
