WHEELS, TIRES 15
183
15.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 148)
– Lift the motorcycle with the front lifting gear. ( p. 149)
K01365-10
Main work
–
Remove screw
1
and pull wheel speed sensor
2
out of the
hole.
–
Remove screws
3
.
– Press back the brake linings by slightly tilting the left brake
caliper laterally on the brake disc. Pull the left brake caliper
carefully back from the brake disc and hang to the side.
Info
Do not operate the hand brake lever if the brake caliper
has been removed.
–
Remove screws
4
.
– Press back the brake linings by slightly tilting the right brake
caliper laterally on the brake disc. Pull the right brake caliper
carefully back from the brake disc and hang to the side.
Info
Do not operate the hand brake lever if the brake caliper
has been removed.
