ELECTRICAL SYSTEM 16
223
F02773-10
–
Hold turn signal in the area
A
and carefully press against the
direction of travel.
The cover is detached as illustrated.
– Repeat the operation on the opposite side.
– Take off the cover.
16.11 Installing the cover of the headlight mask rack
F02773-10
Main work
– Position cover by guiding the plug-in connector of the head-
light through the opening.
–
Hold turn signal in the area
A
and carefully press against the
direction of travel, while pressing the cover tight at the same
time.
The cover engages with an audible click.
– Repeat the operation on the opposite side.
