6 CONTROLS
30
K01352-10
Overview of the left combination switch
1
Light switch ( p. 30)
2
Menu buttons ( p. 34)
3
Turn signal switch ( p. 35)
4
Horn button ( p. 36)
6.4.2 Light switch
V01191-10
Light switch
1
is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch in position
A
. In this
position, the low beam and the tail light are switched
on.
High beam on – Push the light switch to position
B
.
In this position, the high beam and the tail light are
switched on.
Headlight flasher – Push the light switch into posi-
tion
C
.
