COMBINATION INSTRUMENT 7
57
Info
The figure shows the start screen of the combination instrument. If the menu is opened, the speed is still
displayed.
1
Gear display
2
Heated grip (optional) ( p. 59)
3
Cruise control indicator (optional) ( p. 60)
4
Bluetooth
®
(optional)
5
Ride Mode ( p. 241)
6
Unit for the speedometer
7
Fuel level display ( p. 60)
8
Coolant temperature indicator ( p. 61)
9
Range display
bk
Speed
bl
trip odometer ( p. 62)
bm
Ambient temperature
bn
Time ( p. 63)
bo
ABS display ( p. 63)
bp
Tachometer
bp
Shift warning light ( p. 64)
The shift warning light is integrated in the tachometer display.
