4 TECHNICAL DATA
20
Screw, activated carbon filter
holder
M6 6 Nm (4.4 lbf ft)
Screw, angle sensor M6 5 Nm (3.7 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, battery support bracket M6 4.5 Nm (3.32 lbf ft)
Screw, battery terminal M6x12 4.5 Nm (3.32 lbf ft)
Screw, battery terminal M6x20 4.5 Nm (3.32 lbf ft)
Screw, brake assembly M6 5 Nm (3.7 lbf ft)
Screw, clutch assembly M6 5 Nm (3.7 lbf ft)
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, foot brake lever stub M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, front rider's seat M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, fuel tank rollers M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, fuel tank spoiler M6 3 Nm (2.2 lbf ft)
Screw, ground wire on frame M6 6 Nm (4.4 lbf ft)
Screw, ground wire to starter motor M6 10 Nm (7.4 lbf ft)
Screw, ignition lock (tamper-proof
screw)
M6 Tighten until the head tears off.
Loctite
®
243™
Screw, license plate holder M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, magnetic holder on side
stand
M6 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, main silencer clamp M6 8 Nm (5.9 lbf ft)
Screw, manifold clamp M6 8 Nm (5.9 lbf ft)
Screw, radiator bracket, bottom M6 5 Nm (3.7 lbf ft)
Screw, seat lock M6 8 Nm (5.9 lbf ft)
Loctite
®
222™
Screw, shift lever stub M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift rod M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift shaft deflector on shift
shaft
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, wheel speed sensor M6 6 Nm (4.4 lbf ft)
Nut, manifold on cylinder head M8 Tighten the nuts evenly. Do not
bend the metal.
20 Nm (14.8 lbf ft)
Copper paste
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Pin, rear brake caliper M8 14 Nm (10.3 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
