KTM 890 DUKE R 2022 - Page 23

TECHNICAL DATA 4
21
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, cross member M8x18 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, cross member in rear M8x35 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, engine fixing arm linkage
bracket
M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, foot brake lever M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, footrest bracket, rear M8x25 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, footrest bracket, rear M8x40 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake disc M8 28 Nm (20.7 lbf ft)
Loctite
®
2701™
Screw, grab handle M8x50 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, main silencer fastening M8 15 Nm (11.1 lbf ft)
Screw, main silencer holder M8x25 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, main silencer holder M8x40 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, main silencer holder M8x45 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, main silencer holder M8x60 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, passenger seat bracket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, presilencer on frame M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, rear brake disc M8 28 Nm (20.7 lbf ft)
Loctite
®
2701™
Screw, shift lever M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Screw, spring holder plate on side
stand bracket
M8 15 Nm (11.1 lbf ft)
Loctite
®
2701™
Screw, steering damper on holder M8 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, steering damper on triple
clamp
M8 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, steering stem M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, subframe brace M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 15 Nm (11.1 lbf ft)
Engine carrying screw M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
