TECHNICAL SPECIFICATIONS – CHASSIS »
CHASSIS 950 SUPER ENDURO R
Battery 12V 11.2 Ah maintenance-free
Steering head angle 64.4°
Wheel base 1577 ± 10 mm (62 in)
Seat height, unloaded 965 mm (38 in)
Ground clearance, unloaded 330 mm (13 in)
Dry weight 190 kg (419.4 lbs)
Max. axle load, front 190 kg (419.4 lbs)
Max. axle load, rear 250 kg (552 lbs)
Max. total weight 400 kg (883 lbs)
FORK 950 SUPER ENDURO R
Type 14187B32 WP Suspension
Spring 5.9-450
Spring preload (turns) 5
Air chamber lenght 100 mm (4 in)
Fork oil SAE 5 (WP 4860.0401)
SHOCK ABSORBER 950 SUPER ENDURO R
Type 15187B06 WP Suspension
Spring 140-215
Spring preload (mm) 8 mm (0.31 in)
950 SUPER
ENDURO R 2006
FORK SHOCK
SETTING
Compression
Rebound
Spring preload
(turns)
Compression
Low Speed
Compression
High Speed
Rebound
Spring preload
(mm)
Comfort 25 25 1 25 2 22 8
Basic Setting 20 20 5 20 1.5 18 8
Sport (MX)
15 15 8 15 1 15 8
Max. payload 20 20 5 15 1 15 8
76
