KTM 950 R User Manual

TECHNICAL SPECIFICATIONS – CHASSIS »
TIGHTENING TORQUES – CHASSIS 950 SUPER ENDURO R 2006
Bolt for side stand switch M4 2 Nm
Drain plug on oil tank M12x1,5 25 Nm
Exhaust nuts on manifold M8 evenly, do not bend sheet metal
Exhaust clamp M8 12 Nm
Senkschraube Hitzeschutzblech M6 8 Nm
HH bolt on fuel level indicator M5 3 Nm
HH bolts fuel taps M6 6 Nm
Collar screw for underride protection M8 25 Nm
Spoke nipple M5 5 Nm ± 1 Nm
Jerk damper bolt rear wheel M10x1,25 Loctite 243 + 50 Nm
Chainguard M5 5 Nm
Chain sliding guard M5 5 Nm
Taillight M6 8 Nm
Other bolts on chassis M6
M8
M10
10 Nm
25 Nm
45 Nm
Other collar nuts on chassis M6
M8
M10
15 Nm
30 Nm
50 Nm
