MAINTENANCE WORK ON FRAME AND ENGINE 132
100587-10
– Remove fuse box cover .
100588-11
– Remove the faulty fuse.
Guideline
Fuse IGNITION, FUEL PUMP - 10A - ignition, fuel pump, immobilizer, alarm system
(optional)
Fuse H/L BEAM, POSITION - 15A - high beam, low beam, parking light, license plate
lamp
Fuse HORN, BRAKE LIGHT - 10A - horn, brake light, hazard warning flasher
Fuse FAN - 10A - radiator fan
Fuse POWER RELAY - 10A - ignition (EFI control unit)
Fuse ACC1, CLOCK - 10A - combination instrument, socket, supplementary devices
(permanent positive), alarm system (optional)
Fuse ACC2 - 10A - supplementary equipment (accessories connected to the ignition
switch)
(990 Adventure USA)
Fuse ABS, OPTIONAL - 10A - ABS
(990 Adventure R USA)
Fuse ABS, OPTIONAL - not used
