MAINTENANCE WORK ON FRAME AND ENGINE 149
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
– Avoid contact between fuel and skin, eyes and clothing. Do not inhale fuel vapors. If fuel gets into your eyes, rinse immediately
with water and contact a doctor. Wash affected skin areas immediately with soap and water. If fuel is swallowed, contact a doc-
tor immediately. Change clothing that has come into contact with fuel. Store fuel in a suitable canister according to regulations
and keep it out of the reach of children.
– Clean the fuel hose connection and check the O-ring for damage.
100618-11
– Position the fuel tank at about the same height as when mounted to connect the hoses
and plug-in connectors.
– Attach fuel hose to the fuel tap and push the hose clamp forward.
– Connect the fuel hose connection .
– Attach hose to the connector.
– Connect the plug-in connector of fuel pump and fuel level indicator .
100617-11
– Raise the fuel tank slightly and attach it to the upper holder.
– Mount and tighten screws .
Guideline
Screw, fuel tank M8 15 Nm
(11.1 lbf ft)
–
Install the storage compartment. x (
p. 146)
– Install the front side cover. ( p. 134)
– Turn the knurled screws on both fuel taps counterclockwise as far as possible.
– Check the fuel system for leaks.
