M.5
ELECTRICAL SYSTEM
68
mm
STROKE SERIES WSM,
01
160
OFF
ARRET
ON
MARCHE
[2]
CHARGING
SYSTEM
(1)
Dynamo
0339F516
(2)
Regulator
[A] General wiring dia ram
Diagramme de
cab%
e general
Allgemeines
Schalts
Aema
I
I
0203F013
I
ON
Only the terminal "AC"
is
connected to the
battery.
At any position of the
key
except the
"OFF"
position, the terminal
"AC"
is
connected to the
"BAT" terminal.
(1)
From Battery
(2)
To
Regulator
(3)
To
Oil
Pressure Lamp and
accessory
This dynamo
is
an
8-8
pole rotating magnet type
generator.
It
is
simple in construction, consisting of
a
stator and rotor. The rotor
is
made up of eight
permanent magnet pole pieces assembled on
a
shaft
and rotates on the center of the stator around which
eight electromagnetic coils are provided for. This
dynamo produces higher voltage
in
slow
speed
rotation, and charges electric current to the battery
during engine idling.
The regulator performs rectification and voltage
regulation. The regulator converts AC into DC which
flows
through the
power
consuming circuits and
the
battery, and also charges the battery.
If
however, the
battery voltage
exceeds
a
certain
level.
The
DC
current
is
cut
off
from
the
charging circuit to prevent
overcharging.
(1)
Regulator
(6)
Blue Lead Wire
(2)
Dynamo
(7)
Yellow Lead Wire
(3)
Load
(8)
Red Lead Wire
(4)
Charge Lamp
(9)
Green Lead Wire
(5)
Battery
(IO)
Black Lead Wire
