PERIODIC SERVICE54
BChanging Rear Axle Differential Case
Fluid [4WD]
(See "LUBRICANTS, FUEL AND COOLANT" in
"MAINTENANCE" section.)
Remove the drain and filling port plug. After draining,
replace the drain plug and fill with new oil.
BChanging Rear Axle Gear Case Fluid
[4WD]
(RIGHT AND LEFT) (See "LUBRICANTS, FUEL AND
COOLANT" in "MAINTENANCE" section.)
1. To check the oil level, remove the check plug (bolt).
A Place the mower on a level surface.
Loosen the check plug. Oil should be visible
through the opening. If the oil level is too low or
high, adjust it.
2. To change gear oil, remove the drain and filling port
plug with the hex head wrench to drain the used oil.
After draining, replace the drain plug and fill with new
oil.
Oil capacity 1.5 L
(1) Filling plug with dipstick
(2) Drain plug
(A) Oil level is acceptable within
the range
Oil capacity 0.5 L
(1) Filling and checking port plug
(2) Drain plug
(3) Hex head wrench
To Next Page
