59PERIODIC SERVICE
BReplacing Light Bulb
1. Head light
Take the bulb out of the light body and replace with a
new one.
2. Other lights
Detach the lens and replace the bulb.
BBleeding Fuel System
Air must be removed:
1. When the fuel filter or lines are removed.
2. When tank is completely empty.
3. After the machine has not been used for a long period
of time.
C Bleeding procedure is as follows:
1. Fill the fuel tank with fuel.
2. Start the engine and run for about 30 seconds, and
then stop the engine.
3. Open the bleed screw.
When bubbles disappear from fuel coming out of the
plug, tighten the bleed screw.
BAdjusting Lift Springs (LH & RH)
In order to help improve traction, adjust the lift springs
according to the chart below.
Light Capacity
Headlight 55W
(1) Bleeding screw
RCK72P-F39, RCK72R-F36,
RCK60P-F39, RCK60R-F36
RH L = 50 mm
LH L = 70 mm
(L) RIGHT HAND: 50mm
LEFT HAND: 70mm
To Next Page
