Kubota LX3310 User Manual

UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and
controls. The symbols are shown below with an indication of their meaning.
General
Safety alert symbol
Master system warning
Fast
Slow
Read operator's manual
Lock
Unlock
Engine-related
Diesel fuel
Fuel level
Hour meter / elapsed operating hours
Engine coolant - temperature
Engine oil - pressure
Water separator
Engine - warning
Engine speed control
Engine - rotational speed
Engine - rpm increase
Engine - run
Engine - start
Engine - stop
Diesel preheat / glow plugs (low
temperature start aid)
Emission control
Regeneration
Regeneration inhibit
Regeneration (switch)
Parked regeneration
Vehicle body-related
Tractor forward movement - overhead
view
Tractor rearward movement -
overhead view
4-wheel drive - on
4-wheel drive - off
Cruise control / speed set
Clutch
Brake
Parking brake
Differential lock
Steering wheel - tilt control
UNIVERSAL SYMBOLS
LX2610,LX3310
1

Kubota LX3310 Specifications

General

Engine Type	Diesel
Drive	4WD
Cylinders	3
Transmission Type	Hydrostatic
Hydraulic System Type	Open center
3-Point Hitch Category	Category I
Transmission	Hydrostatic
Fuel Capacity	8.5 gal
Displacement	91.5 cu in
Lift Capacity at 24" behind lift point	881 lbs (400 kg)
Length	115.2 in (293 cm)
Height	87.4 in (222 cm)
