17OPERATING THE ENGINE
ENGLISH
STOPPING THE ENGINE
1. After idling the engine, turn the key switch to
"OFF" position.
2. Remove the key.
3. Do not leave the key switch "ON" (key in the "ON"
position) as the battery will discharge when the
engine is not running.
4. Apply the parking brake.
BEngine Stop Lever (Inside the Hood)
The engine stops when the key switch is turned "OFF". If
the engine does not stop, make sure the motion control
levers are in the "NEUTRAL LOCK" position, the PTO
lever is "OFF", the mower lowered to the ground and
apply the parking brake, then carefully get off the
machine. Then open the hood and pull engine stop lever
(Red mark) and hold it until the engine stops. Then
contact your local KUBOTA Dealer immediately.
To avoid personal injury:
A Do not operate the machine until the engine
stop system is repaired.
(1) Engine stop lever

Kubota ZD221 Specifications

General

Style	Zero Turn
Color	Red
Cutting Width	48/54 in
Cutting Height	1-5 in
Cutting Method	-
Number of Blades	3
Drive System	Cruise Control (Hydrostatic)
Case Size: U1R	CCA: 450A
Noise Level	-
Features	Superior Quality Cut
Accessories	-
Motor / Engine Model	Kubota D782
Power Output	-
Cylinders	3
Generator	-
Power / Fuel Type	Diesel
Fuel Tank Volume	23.0 liters (6.1 US gal.; 5.1 Imp. gal)
SAE 5W30 (below 32°F/0°C)	SAE 5W30
w/o Filter: 44 oz. (1	1.32 Imp. qt.)

Weight and Dimensions

Depth	2130 mm (83.9 in)
Height	1770 mm (69.7 in)
Width	1210 mm (47.6 in)
Net Weight	550 kg (1213 lbs)
