KUHN GMD55 SELECT - Technical Specifications; Sound Levels

Disc mower
20
GMD55 SELECT
Machine specifications
2. Technical specifications
3. Sound levels
Attachment type 3 point linkage category 1 and 2
Number of discs 5
Working width 2.00 m (6’7’’)
Width in working position 3.92 m (12’1’’)
Height in working position 1.15 m (3’9’’)
Length in working position 2.35 m (7’9’’)
Width in transport position 1.72 m (5’8’’)
Height in transport position 2.57 m (8’5’’)
Length in transport position 2.00 m (6’7’’)
Disc rotational speed 3030 min
-1
PTO speed 540 min
-1
Weight 405kg(893lb)
Minimum PTO power requirement 25 kW (35 hp)
Sound levels have been measured in accordance with the measuring methods as defined in:
NF EN 1553
"Agricultural machinery - Self-propelled, mounted, semi-mounted and trailed - Common safety
recommendations"
Weighted equivalent continuous acoustic pressure level at the driver's seat (closed cabin) L (A) eq:
Tractor only: 81.1 dB(A)
Tractor + machine: 81.9 dB(A)
