Disc mower
32
GMD55 SELECT
Instructions for transport
$Instructions for transport
1. Putting the machine into transport
position
From the working position:
- Lift the machine with the tractor's three point linkage.
- Remove lynch pin (1) and pin (2).
- Lock compensation system in transport position using
pin (2) and lynch pin (1).
- Unlock and lift front guard using 16mm box spanner
supplied with the machine.
- The guard locks automatically.
Before placing the machine into transport
position:
- Check that nobody is within the machine
pivoting area.
- If there is someone, make sure the
person moves away.
