Putting into service
Disc mower
GMD55 SELECT
31
- Activate the transport/work cylinder control valve in
the "pivot into work" position.
- Lift the machine with the tractor's three point linkage.
- Press push-button (1) and lower parking stand (2)
until push-button engages in position (3).
- Lower the tractor three-point linkage to rest the
machine on the ground.
- Detach the top link from the machine end.
- Uncouple the PTO shaft.
- Support PTO shaft with check chain attached around
the hitch pin (1).
- Disconnect hydraulic hose from tractor.
- Release the lower links.
- Lower the tractor three-point linkage.
The machine is uncoupled.
