Disc mower
26
GMD883
Putting into service
Description of the controls
ON/OFF push button (a).
Control box area selector:
Toggle switch (1) in position (a) activates area (2).
Toggle switch (1) in position (b) activates area (3).
The warning light is on when the control box is
energized.
The direction of operation of different functions
may be inverted depending upon the way the
hydraulic hoses have been connected to the
tractor outlet.
