Power harrows
32
HRB353D - 403D
Putting into service
Adjustment
- Remove screw (1).
- Remove pin (2).
- Fit lower coupling yoke (3) in the required position.
- Insert pin (2).
- Reinstall screw (1).
Torque screw (1) to 6 daN m (44 lbf ft).
- Proceed the same way on the other side.
Check that the 2 lower links have been adjusted
identically.
