Power harrows
34
HRB353D - 403D
Putting into service
- Attach top link with hitch pin.
• Use tractor and machine attachment holes to adjust
the top link position.
- Insert hitch pin anti-rotation arm (1) in the machine
mounting yoke and secure with lock pin.
When the tractor is fitted with a standard 3 point
attachment category 2, use category 2 upper
hitch pins Part no. 52596900 (Available as
spare part).
When the tractor is fitted with a standard 3 point
attachment category 3, use category 3 upper
hitch pins Part no. 52597000 (Factory supplied).
To obtain optimum PTO shaft angles and
tractor lift capacity, the top link must be
parallel to the lower links or slightly pointing
downwards towards the tractor.
