Putting into service
Power harrows
HRB353D - 403D
41
Spring cartridge adjustment:
- Measure dimension L (Using a vernier caliper).
- Note : On first removal of the slip clutch, use Graph
below to determine measurement L. The measure L
will usually be found to be between 51.7 and 52.5 mm
(2.03’’ - 2.06’’).
- Adjust measure L to the required length.
By increasing the dimension L, the release effort
is reduced and vice versa.
