Power harrows
48
HRB353D - 403D
Putting into service
Adjusting the side deflectors
The deflector position must be adapted to:
- The working depth.
- The blade wear.
- Loosen screw (1).
- Remove screw (2).
- Place the defletor in the required position:
• Position (a) corresponds to the lower deflector
position.
• Position (b) corresponds to the upper deflector
position.
- Reinstall and tighten screw (2).
- Tighten screw (1).
The deflectors are factory fitted in the lower
position (a).
