Machine use
Control box
RPB
53
î
Sequential opening/closing of the spraying
sections
Left sequential ope
ning of the spraying se
ctions:
-
Operate switch (1) to the right.
-
Repeat procedure for each se
ction.
Left sequential shutting of th
e spraying sections:
-
Operate switch (1) to the right.
-
Repeat procedure for each se
ction.
1
1
54
